Discovery II
TORQUE WRENCH SETTINGS
06-17
Brakes
TORQUE DESCRIPTION
METRIC
IMPERIAL
Brake caliper bleed screw
10 Nm
(7 lbf.ft)
Brake disc to drive flange
13 Nm
(10 lbf.ft)
Caliper bolts - Front
175 Nm
(129 lbf.ft)
Caliper bolts - Rear
95 Nm
(70 lbf.ft)
Master cylinder to servo
25 Nm
(18 lbf.ft)
Master cylinder brake pipe, unions
25 Nm
(18 lbf.ft)
Brake caliper pivot bolt
30 Nm
(22 lbf.ft)
Vacuum pump
8 Nm
(6 lbf.ft)
Vacuum pump lubrication pipe union
10 Nm
(7 lbf.ft)
Brake caliper guide pin bolts
30 Nm
(22 lbf.ft)
Brake caliper banjo bolt
32 Nm
(24 lbf.ft)
ABS modulator to mounting bracket nuts
9 Nm
(7 lbf.ft)
ABS modulator - 13 mm unions
22 Nm
(16 lbf.ft)
ABS modulator - 11 mm union
14 Nm
(10 lbf.ft)
Handbrake lever to floor bolts
22 Nm
(16 lbf.ft)
