Discovery II
TORQUE WRENCH SETTINGS
06-14
Steering
TORQUE DESCRIPTION
METRIC
IMPERIAL
Drag link to drop arm
80 Nm
(59 lbf.ft)
Track rod to steering knuckle
125 Nm
(92 lbf.ft)
Tension collet to steering knuckle
5 Nm
(3.7 lbf.ft)
Steering damper
125 Nm
(92 lbf.ft)
Steering knuckle to axle yoke upper ball joint
110 Nm
(81 lbf.ft)
High pressure pipe union
20 Nm
(15 lbf.ft)
Drag link/track rod M8 bolts
22 Nm
(16 lbf.ft)
Drag link/track rod M10 bolts
33 Nm
(24 lbf.ft)
Steering box
90 Nm
(66 lbf.ft)
Universal joint to intermediate shaft
25 Nm
(18 lbf.ft)
Panhard rod
230 Nm
(170 lbf.ft)
Steering box output shaft
88 Nm
(65 lbf.ft)
Drop arm
240 Nm
(177 lbf.ft)
Auxiliary housing bolts
40 Nm
(30 lbf.ft)
Auxiliary housing nut
10 Nm
(7 lbf.ft)
PAS pump - V8
22 Nm
(16 lbf.ft)
PAS pump pipe bracket bolt
22 Nm
(16 lbf.ft)
Jockey pulley bolt
50 Nm
(37 lbf.ft)
PAS pump adaptor pipe
10 Nm
(7 lbf.ft)
PAS pump to coolant pump bolts - Td5
25 Nm
(18 lbf.ft)
Steering column to fascia
25 Nm
(18 lbf.ft)
Universal joint to steering box
25 Nm
(18 lbf.ft)
Ball joint to swivel hub
77 Nm
(57 lbf.ft)
PAS pump pulley
22 Nm
(16 lbf.ft)
Steering wheel nut
43 Nm
(32 lbf.ft)
