L322 Range Rover Service Procedures
MANIFOLD AND EXHAUST SYSTEM - V8
REPAIRS
30-2-5
Tail pipe & silencer
$% 30.10.22
Remove
1. Position vehicle on lift.
2. Using LRT-99-027, cut pipe at point indicated
by depression in pipe.
3. Remove 8 nuts securing mountings and with
assistance, remove tail pipe and silencer
assembly.
4. Remove 4 exhaust mountings.
Refit
1. Fit 4 exhaust mountings.
2. Clean intermediate pipe and fit sleeve.
3. With assistance, fit tail pipe and silencer
assembly, locate mountings and fit nuts.
Tighten nuts to 25 Nm (18 lbf.ft).
4. Centralise connecting sleeve over joint, align
intermediate pipe with tail pipe and tighten
sleeve clamp nuts to 48 Nm (35 lbf.ft).
5. Check exhaust for correct alignment.
6. Connect battery earth lead.
7. Start and run engine to check for leaks.
