L322 Range Rover Service Procedures
NAVIGATION AND IN CAR ENTERTAINMENT
REPAIRS
86-7-3
Speaker - front door
$% 86.50.10
Remove
1. Remove front door trim casing.
2. Remove front speaker harness.
3. Disconnect multiplug from speaker.
4. Remove 4 screws securing speaker to door.
5. Remove speaker.
Refit
1. Fit speaker to door and secure with screws.
2. Connect multiplug to speaker.
3. Fit front speaker harness.
4. Fit front door trim casing.
Speaker - top rail
$% 86.50.11
Remove
1. Carefully release speaker grille from top rail
finisher.
2. Remove 4 Torx screws securing speaker to
finisher.
3. Release speaker from mounting and
disconnect multiplug.
Refit
1. Connect multiplug, position speaker to
mounting and secure with screws.
2. Fit and secure grille to top rail finisher.
