LR3 (LA) V8-4.4L (2009)
Electronic Throttle Actuator: Description and Operation
Throttle Control System
Description
The Electronic Throttle Interface consists of 2 PWM output drives to control the throttle blade position, with 2 analogue signals for throttle position
feedback. The 2 position signals have positive linear characteristics.
