Heater Core: Service and Repair
Heater Core - LHD
Heater Core - LHD
Service Repair No - 80.20.29
Removal
1. Drain the cooling system.
2. Remove the instrument panel passenger side reinforcement.
3. Remove the heater core upper and lower pipes.
^
Position a container to collect the fluid.
^
Loosen the 4 screws and remove the clips.
^
Remove and discard the 4 O-ring seals.
4. Remove the heater core.
Installation
1. Install the heater core.
2. Install the heater core upper and lower pipes.
^
Clean the components.
^
Install the new O-ring seals.
^
Install the clips and tighten the screws.
^
Remove the container.
3. Install the instrument panel passenger side reinforcement.
4. Refill the cooling system.
