Range Rover P38
04
GENERAL SPECIFICATION DATA
NEW RANGE ROVER
12
INFORMATION
FUEL SYSTEM - BMW DIESEL ENGINE
Injection pump type
Bosch rotary R515
..........................................................
Injection pump timing
0.95
±
0.02 mm lift at TDC
.......................................................
Injectors
See ENGINE TUNING DATA, Information.
...........................................................................
Heater plugs
See ENGINE TUNING DATA, Information.
.....................................................................
Fuel lift pump type
Electric in tank fuel pump
............................................................
Fuel filter
Paper element type
..........................................................................
Air cleaner
Paper element type
........................................................................
Turbocharger
Mitsubishi TD04 11G4
...................................................................
COOLING SYSTEM - V8 ENGINE
System type
Pressurized, spill return, thermostatically controlled
.....................................................................
water and anti freeze mixture. Vertical flow radiator
with remote header tank and pump assisted.
Cooling fan
9 blade axial flow. Viscous coupling.
.......................................................................
Pump type
Centrifugal, impeller, belt driven.
........................................................................
Thermostat opening
Up to 99MY
88
°
C
.............................................................
190
°
F
From 99MY
85
±
5
°
C
.............................................................
185
±
9
°
F
Expansion tank cap pressure (system pressure)
1.0 bar
.............
15 lbf/in
2
COOLING SYSTEM - BMW DIESEL ENGINE
System type
Pressurized, spill return, thermostatically controlled
.....................................................................
water and anti freeze mixture. Pump assisted thermo
syphon. Coolant radiator combined with oil cooler and
turbo intercooler.
Cooling fan
11 blade axial flow 433 mm diameter. 1.44:1 drive
.......................................................................
ratio. Viscous coupling.
Pump type
Centrifugal, impeller, belt driven.
........................................................................
Thermostat opening
80
°
C
.........................................................
176
°
F
Expansion tank cap pressure (system pressure)
1.0 bar
.............
15 lbf/in
2
