Range Rover P38
06
TORQUE VALUES
NEW RANGE ROVER
10
DATA, TORQUE & TOOLS
V8 petrol:
- PAS pump and compressor mounting bracket to
engine bolts
40
......................................................................
30
- PAS pump to mounting bracket bolts - up to 99MY
18
.......
13
- PAS pump to mounting bracket bolts - from 99MY
22
........
16
- Pulley to PAS pump bolts
25
..............................................
18
Steering wheel bolt
33
...........................................................
24
Pad to steering wheel bolts
8
..............................................
6
Track rods to steering knuckles nuts
50
................................
37
Road wheel nuts
108
..............................................................
80
Composite link to axle nuts:
- M12
125
................................................................................
92
- M16
160
................................................................................
118
Composite link to chassis nut
160
...........................................
118
PAS reservoir to radiator bracket bolt
10
..............................
7
PAS pipes to steering box nut
25
..........................................
18
60 - FRONT SUSPENSION
Air hose to compressor union
7
..........................................
5
Compressor to air supply unit nuts
2
...................................
1.5
Air reservoir to air bracket bolts
25
.......................................
18
Anti-roll bar rubber bush clamp bolts
125
...............................
92
Anti-roll bar link nuts
125
.........................................................
92
Compressor air inlet filter
1
.................................................
0.75
Air drier to bracket
12
............................................................
9
Height sensor retaining bolts:
- 95 & 96 MY
12
....................................................................
9
- 97 MY on
6
.......................................................................
4
Height sensor link to radius arm nut
8
.................................
6
Heat shield bracket/height sensor bolts
6
...........................
4
Heat shield to bracket bolts
6
..............................................
4
Hub and drive shaft assembly bolts
135
.................................
100
Drive shaft nut
260
..................................................................
192
Panhard rod to chassis nut and bolt
200
.................................
148
Panhard rod to axle bolt
200
...................................................
148
Panhard rod to axle securing bolt locking
plate screw
20
.......................................................................
15
Radius arm to chassis
160
......................................................
118
Radius arm to axle nut and bolt
125
.......................................
92
Shock absorber upper retaining bolt
125
................................
92
Shock absorber lower retaining bolt
45
.................................
33
Road wheel nuts
108
..............................................................
80
Swivel hub upper joint to axle nut
110
....................................
81
Swivel hub lower joint to axle nut
160
.....................................
118
Track and drag links to swivel hub nuts
80
...........................
59
Pressure switch to valve block
23
.........................................
17
Solenoid coil to valve block screws
1.5
..................................
1
Front air spring to axle bolt
20
...............................................
15
Air distribution box to body bolt
6
........................................
4
Air drier to air cleaner bolt
3
................................................
2
