LUBRICANTS, FLUIDS AND CAPACITIES
NEW RANGE ROVER
4
INFORMATION
CAPACITIES
The following capacity figures are approximate and provided as a guide only. Refer to Section 10 for correct
checking procedure for powertrain oil levels.
Engine sump and filter - Petrol
From dry
6.6 litres
..................................................................
14.0 US pints
Refill
5.8 litres
........................................................................
12.3 US pints
Engine sump and filter - Diesel
From dry
9.5 litres
..................................................................
20 US pints
Refill
8.7 litres
........................................................................
18.4 US pints
Manual gearbox
From dry
2.7 litres
..................................................................
5.7 US pints
Refill
2.2 litres
........................................................................
4.6 US pints
Automatic gearbox
4.6 V8 up to ’99MY
11 litres
..................................................
23.2 US pints
4.0 V8 (& 4.6 V8 from ’99MY)
9.7 litres
.................................
20.5 US pints
Diesel
9.7 litres
......................................................................
20.5 US pints
Transfer box
From dry
2.4 litres
..................................................................
5.0 US pints
Refill
2.0 litres
........................................................................
4.2 US pints
Front axle
From dry
1.7 litres
..................................................................
3.6 US pints
Refill
1.6 litres
........................................................................
3.4 US pints
Rear axle
From dry
1.7 litres
..................................................................
3.6 US pints
Refill
1.6 litres
........................................................................
3.4 US pints
Power steering box and reservoir
1.7 litres
....................................
3.6 US pints
Cooling system
11.3 litres
................................................................
24 US pints
Fuel tank
Petrol
100 litres
.......................................................................
26.4 US gallons
Diesel
90 litres
......................................................................
24 US gallons
Air conditioning system
Refrigerant charge weight
V8 up to 99MY
1250 grammes
................................................
44 oz
V8 from 99MY
1380
±
25 grammes
................................................
49
±
1 oz
Diesel
1100 grammes
.............................................................
39 oz
Refrigerant oil in system
V8 up to 99MY
150 cm
3
................................................
0.32 US pint
V8 from 99MY
180 cm
3
................................................
0.38 US pint
Diesel
140 cm
3
.............................................................
0.30 US pint
