Range Rover P38
SUPPLEMENTARY RESTRAINT SYSTEM
1
REPAIR
AIRBAG MODULE - PASSENGER SIDE
Service repair no - 76.73.69
WARNING: All the airbag system
components, including the wiring harness,
MUST be renewed after the airbags have
deployed.
Remove
1. Disconnect both battery terminals, disconnect
negative lead first.
2. Remove glove box assembly.
See CHASSIS
AND BODY, Repair.
3. Remove veneered panel from passenger side of
fascia.
See CHASSIS AND BODY, Repair.
4. Release and disconnect air bag module
multiplug.
5. Remove 4 bolts and washers (E-10 Torx Bit)
securing air bag module to fascia frame.
6. Carefully release and remove air bag module.
CAUTION: Store the airbag module
correctly.
See this section.
Refit
NOTE: If a new airbag module is being
fitted the serial numbers must be
recorded.
7. Carefully fit air bag module to fascia. Fit Torx
bolts, and washers.
8. Tighten bolts to
9 Nm. (7 lbf.ft)
9. Connect air bag module multiplug and secure to
location.
10. Fit glove box assembly.
See CHASSIS AND
BODY, Repair.
11. Connect battery terminals, fit battery cover and
secure with turnbuckles.
12. Check Supplementary Restraint System using
TestBook .
