MANUAL GEARBOX
OVERHAUL
15
4. Invert output shaft and using LRT-99-002 and
support bars under 3rd gear, press off pilot
bearing.
5. Remove spacer, 3rd/4th gear synchromesh
selector hub, synchromesh baulk rings, 3rd
gear and needle bearing.
Gearcase
Degrease and clean all components. Inspect casing
for damage, cracks and stripped threads.
1. Fit oil filer/level plug.
CAUTION: Attach a suitable label
indicating gearbox oil is drained.
2. Fit new sealing washer to drain plug, fit plug
and tighten to 50 Nm (37 lbf.ft).
