GS 300 L6-3.0L (2JZ-GE) (1993)
Cruise Control
System Information
System Diagnosis / Reading and Clearing Diagnostic Trouble Codes
Page 4749
Page 8
Fig. 10 ECU Circuit Test Chart (Part 2 Of 2)
Cruise Control
System Information
System Diagnosis / Reading and Clearing Diagnostic Trouble Codes
Page 4749
