GS 350 RWD V6-3.5L (2GR-FSE) (2007)
Brake Bleeding: Service and Repair
BLEEDING
HINT: If any work is performed on the brake system or if air in the brake lines is suspected, bleed the air from the brake system.
NOTICE:
^
Move the shift lever to the P position and apply the parking brake before bleeding the brakes.
^
Add brake fluid to keep the level between MIN and MAX lines of the reservoir while bleeding the brakes.
^
If brake fluid leaks onto any painted surface, wash or otherwise remove it completely.
1. ADD RESERVOIR WITH BRAKE FLUID
(a)
Add reservoir with brake fluid.
Fluid: SAE J1703 or FMVSS No. 116 DOT3
2. BLEED MASTER CYLINDER
HINT:
^
If the master cylinder is reinstall or if the reservoir becomes empty, bleed the air from the master cylinder.
^
To avoid brake fluid from adhering, cover the painted surface with a shop rag or peace of cloth.
(a)
Disconnect the 2 brake lines from the master cylinder.
(b) Slowly depress the brake pedal and hold it.
(c)
Cover the 2 outer holes with fingers, and release the brake pedal.
(d) Repeat (b) and (c) 3 or 4 times.
(e)
Using SST, connect the brake lines to the master cylinder.
SST 09023-00101
Torque: 15 N*m (155 kgf*cm, 11 ft.*lbf)
