RX 300 FWD V6-3.0L (1MZ-FE) (1999)
Cellular Phone: Technical Service Bulletins
Cellular Phone - Installation Correction
BULLETIN NUMBER:
AX003-98
DATE:
August 14, 1998
TITLE:
CORRECTION TO CELLULAR MOBILE TELEPHONE INSTALLATION INSTRUCTIONS
MODELS:
'99 RX 300
INTRODUCTION
This bulletin corrects the instructions for installation of the Portable Plus and Fixed Mobile Cellular Telephones into the RX 300.
AFFECTED VEHICLES
-
1999 model year RX 300
INSTALLATION PROCEDURE CHANGES:
RX 300 FIXED MOBILE TELEPHONE
1. Change Step 2.7 on Page 14-3 to read "2.7a and then add the following step:"
b. Make a (+) cut in the adhesive cover and apply to inside of console tray over 1" hole.
2. Delete the word "Grommet" in the illustration for steps 2.8a through 2.8c on Page 14-3.
3. Change Step 2.8a on Page 14-3 to read "2.8a Route coil cord through hole and connect to handset:'
RX 300 PORTABLE PLUS TELEPHONE
