Power Mirror Switch: Service and Repair

REMOVAL

1. Pry the outside rear view mirror motor out from the front door trim panel.

CAUTION:  Use a shop towel or similar material between the pry tool and the front door trim panel or damage to the front door trim panel may
occur.

2. Disconnect the electrical connector and remove the outside rear view mirror control switch.

INSTALLATION

1. Follow the removal procedure in reverse order.
