Continental V8-4.6L DOHC VIN V (1998)

Page 5
background image

4. Connect the spring lock coupling fittings with a twisting motion until the A/C tube lock coupling spring snaps over the flared end of the female

fitting.

5. Install the A/C tube lock coupling clip.
