Town Car V8-4.6L VIN V Flex Fuel (2006)
4. WARNING: The support straps are load-bearing components during a crash event. The support straps must be correctly installed
during assembly of the seat track. Failure to follow these instructions may result in the failure of the seat to perform as designed with
resultant risk of personal injury to the vehicle occupant.
Install the support straps.
-
The support straps must fit flush against the front and rear height adjustment gears.
5. Check to make sure the index marks on the outboard track C-channel and plastic-coated slide are still in alignment.
6. WARNING: The pinion cage is a load-bearing component during a crash event. The pinion cage must be correctly installed during
assembly of the seat track. Failure to follow this instruction may result in the failure of the seat to perform as designed with resultant risk
of personal injury to the vehicle occupant.
Position the pinion cage onto the outboard track.
7. Install the outboard track.
1
Position the track studs through the seat track motor assembly.
2
While sliding the track studs through the seat track motor assembly, position the pinion cage opening around the seat track motor assembly
gear.
3
Fit the support straps and seat track motor assembly gear bushing alignment pins into the track openings.
