Oil Filter Adapter|Service and Repair|Page 2622 > < Oil Filter Adapter|Service and Repair
Page 2
background image

Removal

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to Maintenance/Service and Repair.
2. Drain the cooling system. For additional information, refer to Cooling System.
3. Disconnect the lower radiator hose from the oil filter adapter.
4. Drain the engine oil.

^

Install the drain plug when finished.

^

Tighten to 13 Nm (10 ft. lbs.).

5. Remove the oil filter.
6. Disconnect the oil pressure sensor electrical connector and detach the wire harness retainer.
7. If equipped, remove the oil cooler hose bolt and the oil cooler hoses from the oil filter adapter.
8. Remove the 4 bolts and the oil filter adapter and gasket.

^

Discard the oil filter adapter gasket.
