Town Car V8-4.6L VIN V Flex Fuel (2006)
24. Align the 4 driver air bag module locking pins to the openings in the steering wheel and position the driver air bag module in place.
25. With the locking pins aligned and the driver air bag module positioned to the steering wheel, push inward seating the 4 locking pins to the spring
clip.
-
An audible click should be heard when the driver air bag module locking pins are seated in place to the spring clip. When the four locking pins
are seated in place, there should be an even uniform gap between the driver air bag module trim cover and the steering wheel.
Warning: The restraint system diagnostic tool is for restraint system service only. Remove from vehicle prior to road use. Failure to remove
could result in injury and possible violation of vehicle safety standards.
26. Make sure all restraint system diagnostic tool(s) that may have been installed during the repair have been removed from the vehicle and all SRS
components are connected.
