Town Car V8-4.6L VIN V Flex Fuel (2006)
5. Clean and inspect the transmission fluid pan, transmission fluid pan gasket and magnet.
6. Thoroughly flush the cooler tubes.
Refill
7. Position the magnet into the transmission fluid pan.
8. NOTE: The fluid pan gasket is reusable, clean and inspect for damage. If not damaged, the gasket should be reused.
Install the fluid pan and gasket.
1
Position the fluid pan with the gasket in place.
2
Install the bolts.
-
Tighten to 14 Nm (10 ft. lbs.).
9. CAUTION: The use of any other transmission fluid can result in the transmission failing to operate in a normal manner or transmission failure.
Fill the transmission.
^
Add 4.7 liters (5 qts) of clean automatic transmission fluid to the transmission through the fluid filler tube.
10. Start the engine. Move the transmission range selector lever through all the gear ranges, checking for engagements.
11. With the engine running and the transmission at normal operating temperature 66 - 77 degrees C (150 - 170 degrees F), check and adjust the
transmission fluid level, and check for any leaks. If fluid is needed, add fluid in increments of 0.24 liter (0.5 pint) until the correct level is
achieved (fluid should be in the cross-hatched area of the fluid level indicator).
