Town Car V8-4.6L VIN V Flex Fuel (2006)
fuel-related components. Highly flammable mixtures are present and may be ignited. Failure to follow these instructions can result in personal
injury.
CAUTION:
-
If the liquid or vapor tube is damaged (torn, holes or delaminated), the affected tube assembly must be replaced with a new tube
assembly. Do not use aftermarket sleeving. Do not re-adhere loose sleeving material.
-
When reusing liquid or vapor tube connectors, make sure to use compressed air to remove any foreign material from the connector
retaining clip area before separating from the tube. Apply clean engine oil to the end of the tube before inserting the tube into the
connector.
-
Fuel injection equipment is manufactured to very precise tolerances and fine clearances. It is therefore essential that absolute cleanliness
is observed when working with these components. Always install blanking plugs to any open orifices or tubes.
1. Disconnect the lock tab on the connector.
2. Separate the connector from the fitting.
Connect - Type II
1. Connect the lock tab and install the connector onto the fitting.
