Town Car V8-4.6L VIN V Flex Fuel (2006)
Body Control Module: Service and Repair
Driver Seat Module (DSM)
DRIVER SEAT MODULE (DSM)
Removal and Installation
1. CAUTION: Prior to removal of the module, it is necessary to upload the module configuration information to a diagnostic tool. This
information needs to be downloaded into the new module once installed.
Remove the driver seat.
2. Remove the 2 DSM screws.
3. Disconnect the DSM electrical connectors.
4. Remove the DSM from the seat bracket.
5. CAUTION: Once the new module is installed, it is necessary to download the module configuration information from the diagnostic tool
