Town Car V8-4.6L VIN V Flex Fuel (2006)
6. NOTE: The RCM has been removed for clarity.
Connect the large RCM electrical connector.
-
Using the connector position assurance lever, pivot it toward the RCM, drawing the connector into the RCM.
-
Make sure the thumb tab is engaged to the retainer on the RCM and is locked in place.
7. Install the insulator on top of the RCM.
8. Install the ashtray bracket.
1
Position the ashtray bracket to the instrument panel.
2
Install the screws.
9. Install the ashtray.
-
Attach the wire harness and connect the cigarette lighter.
