Town Car V8-4.6L VIN V Flex Fuel (2006)
10. Make sure the J-clips on the back of the passenger air bag module are fully seated into the slots.
11. Make sure the retaining clips on the back of the passenger air bag module are fully seated onto the ears.
Caution: Do not handle the passenger air bag module by grabbing the edges of the deployment doors.
12. Install the passenger air bag module into the instrument panel.
-
Make sure the 2 retaining clips and 2 alignment pins are fully seated into the instrument panel. The passenger air bag module should have a
flush fit and finish up against the instrument panel.
13. Through the glove compartment opening, install the passenger air bag module bolts.
-
Tighten to 9 Nm (80 lb-in).
