Steering Wheel > < Steering Shaft|Service and Repair
Page 2
background image

3. Remove the 2 upper intermediate shaft bearing nuts.

^

To install, tighten to 11 Nm (8 ft. lbs.).

4. Remove and discard the lower intermediate shaft-to-steering gear bolt and remove the shaft.

^

To install, tighten to 30 Nm (22 ft. lbs.).

5. To install, reverse the removal procedure.
