Page 3
background image

7. Pull down evenly and remove the transmission fluid filter and seal.

8. Clean and inspect the transmission fluid pan, transmission fluid pan gasket and the magnet.

9. Remove the manual control valve detent lever bolt and spring.

10. NOTE:  Use a shop cloth to protect the transmission case surface.

Remove the manual lever shaft retaining pin.
