Install the driveshaft.
^

Align the index marks and position the driveshaft on the transmission.

^

Install the driveshaft.

21. NOTE:  To maintain driveshaft balance, install the driveshaft yoke and flange in the original position that was marked during removal.

Install the 4 retaining bolts.
^

Tighten to 103 Nm (76 ft. lbs.).

22. Lower the vehicle.
23. Check the level of the transmission fluid, add clean automatic transmission fluid as necessary.
