If there is continuity, inspect the coupler component.
-
If the coupler component is normal, perform an off-vehicle inspection of VSS.
NOTE:
-
Inspect with a tester that can indicate more than 10 megohms and confirm that the value is more than 1 megohm.
5. Verify that there is continuity between coupler component terminals B19 and B20.
-
If there is no continuity, inspect the coupler component.
-
If the coupler component is normal, replace the VSS. See: Powertrain Management/Computers and Control Systems/Sensors and Switches -
Computers and Control Systems/Vehicle Speed Sensor/Service and Repair/Vehicle Speed Sensor (VSS) Removal/Installation - AW6A-EL
Off-Vehicle Inspection
1. Connect the VSS terminal 2 to the battery positive terminal, connect the battery negative terminal to VSS terminal 1 through an ammeter set to a
resistance of 100 ohm.
