6 V6-3.0L (2007)
Alignment: Specifications
Front Wheel Alignment
Wagon
WAGON FRONT SUSPENSION
MAXIMUM STEERING ANGLE
Inner ........................................................................................................................................................................................................................ 34°±3°
Outer ....................................................................................................................................................................................................................... 29°±3°
TOTAL TOE-IN
Tire: .............................................................................................................................. 2±4 mm (0.08±0.16 in), Rim inner: 1.4±2.8 mm (0.06±0.12 in)
(degree) ........................................................................................................................................................................................................... 0°11'±0°22'
CASTER ANGLE (REFERENCE VALUE)
Fuel gauge indication
Empty ............................................................................................................................................................................................................. 3°29'±1°
1/4 .................................................................................................................................................................................................................. 3°32'±1°
1/2 .................................................................................................................................................................................................................. 3°34'±1°
3/4 .................................................................................................................................................................................................................. 3°37'±1°
Full ................................................................................................................................................................................................................. 3°39'±1°
CAMBER ANGLE (REFERENCE VALUE)
Fuel gauge indication
Empty to 1/2 ................................................................................................................................................................................................. -0°16'±1°
1/2 to Full ...................................................................................................................................................................................................... -0°17'±1°
