B4000 V6-4.0L SOHC (2005)
Control Module: Service and Repair
TRANSFER CASE SHIFT CONTROL MODULE REMOVAL / INSTALLATION
1. Remove the audio unit.
^
Insert the removal tool.
^
Remove and support the audio unit.
2. Disconnect the audio unit electrical connector and antenna cable.
3. Remove the screws. Disengage the spring clips.
^
Remove the instrument panel finish panel.
4. Remove the 4X4 control module.
1) Disengage the locking tangs and remove the harness connectors.
