B4000 SE Cab Plus 2WD V6-4.0L OHV (1998)
Remove the speed sensor rotor by tapping with a soft-face hammer. Discard the speed sensor rotor.
Ring Gear and Speed Sensor Rotor Installation Note
1. Position ring gear and speed sensor rotor on differential case. The tab on the speed sensor rotor must be aligned with the slot in the differential
case as shown. Start two ring gear retaining bolts through the case into the ring gear to make sure case-to-ring gear bolt hole alignment is achieved.
CAUTION: The tab on the speed sensor rotor must be aligned with the slot in the differential case.
2. Press the ring gear and speed sensor rotor on the differential case using the ring gear as a pilot.
3. Coat the threads of ring gear retaining bolts with sealant. Install bolts and alternately tighten evenly.
Tighten torque: 95 - 115 Nm (70 - 85 ft. lbs.)
