Evaporator Case|Service and Repair|Page 4559 > < Evaporator Case|Service and Repair
Page 2
background image

10. Disconnect the A/C cycling switch connector.

11. Disconnect blower motor electrical connector.
12. Disconnect the blower motor resistor connector.

13. Remove the support bracket.
14. Disengage the windshield washer hose retainer and position aside.

15. Disconnect the vacuum hose.
16. Disconnect the vacuum hose from the retainer and position aside.

17. Remove the A/C hose support retaining bolts from the back of the engine.
18. Disconnect the vacuum harness connector and nut located in the passenger compartment.

Evaporator Case|Service and Repair|Page 4559 > < Evaporator Case|Service and Repair
