B4000 SE Cab Plus 2WD V6-4.0L OHV (1998)
Hose/Line HVAC: Service and Repair
Condenser to Evaporator Line
1. Recover the refrigerant.
2. Disconnect the condenser to evaporator tube from the A/C evaporator core.
3. Disconnect the condenser to evaporator tube from the A/C condenser core and remove the condenser to evaporator tube.
4. Install in the reverse order of removal.
1. Lubricate the O-ring seal with refrigerant oil.
