CX-7 AWD L4-2.3L Turbo (2008)
Cabin Air Filter: Service and Repair
AIR FILTER REMOVAL/INSTALLATION
CAUTION: If the air conditioner is used or the vehicle is driven with the air filter removed, snow or foreign material can penetrate the
blower motor, causing motor lock or damage. As a result, low visibility due to window fogging or air conditioner malfunction could
occur. Do not use the air conditioner or drive the vehicle with the air filter removed.
1. Remove the glove compartment.
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.
