CX-7 AWD L4-2.3L Turbo (2008)
Transmission Speed Sensor: Service and Repair
INPUT/TURBINE SPEED SENSOR REMOVAL/INSTALLATION [AW6A-EL, AW6AX-EL]
Warning
A hot transaxle and ATF can cause severe burns. Turn off the engine and wait until then are cool before replacing the ATF.
1. Disconnect the negative battery cable.
2. Remove the air cleaner component.
3. Remove the under cover.
4. Drain the ATF.
5. Remove the resonance chamber.
6. Remove the thermo valve.
7. Remove the control valve body.
Caution
^
Do not damage the input/turbine speed sensor.
8. Remove the input/turbine speed sensor.
9. Install the input/turbine speed sensor.
Tightening torque:
3.9-6.9 N-m (40-70 kgf-cm, 26-60 in-lbf)
10. Install the control valve body.
11. Install the thermo valve.
12. Install the resonance chamber.
13. Add ATF to the specified level.
14. Install the under cover.
15. Install the air cleaner component.
16. Connect the negative battery cable.
17. Perform the mechanical system test. (See Mechanical System Test [AW6A-EL, AW6AX-EL].) See: Transmission Control Systems/Testing and
Inspection/Initial Inspection and Diagnostic Overview/Mechanical System Test
