Mazdaspeed6 L4-2.3L Turbo (2006)
Radiator Support: Service and Repair
SHROUD PANEL REMOVAL/INSTALLATION
1. Remove the following parts:
1. Hood
2. Front bumper
3. Front combination light
4. Front bumper reinforcement
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.
