Ignition Switch: Service and Repair
Key Reminder Switch

Removal / Installation

1. Remove the dashboard.
2. Disconnect the key reminder switch connector.
3. Extract the key interlock solenoid terminals from the key reminder switch.
4. Remove the screws and the key reminder switch.
5. Install in the reverse order of removal.
