MPV LX 4WD V6-3.0L SOHC (1997)
Main Relay (Computer/Fuel System): Locations
Control System Component Locations
(1) Engine control module
(2) Mass air flow sensor
(3) Camshaft position sensor
(4) Crankshaft position sensor
(5) Throttle position sensor
(6) Engine coolant temperature sensor
(7) Intake air temperature sensor (Dynamic chamber)
(8) Heated oxygen sensor (Front)
(9) Heated oxygen sensor (Rear)
(10) Fuel tank pressure sensor
(11) Power steering pressure switch
(12) Main relay
