MX-5 Miata L4-1.8L DOHC (1996)
-
Loosen the nut and disconnect the tie rod end with the SST.
Lower arm
-
Loosen the nut and disconnect the lower arm with the SST.
Upper arm
-
Loosen the nut and disconnect the upper arm with the SST.
INSTALLATION
Locknut
-
Install new locknut and stake it.
Tightening torque: 167-216 Nm (17-22 rn-kg, 123-159 ft-lb)
DISASSEMBLY
