Transmission Position Switch/Sensor, A/T > < Transmission Mode Switch, A/T|Testing and Inspection
Page 2
background image

4. If not as specified, replace the selector lever knob assembly.
5. If the switch is OK, check the wiring harness. (Hold switch- powertrain control module (Transaxle), Hold switch-Body ground.)
6. Install the front console.
7. Connect the negative battery cable.

Transmission Position Switch/Sensor, A/T > < Transmission Mode Switch, A/T|Testing and Inspection
