MX-6 L4-2184cc 2.2L SOHC Turbo F2 (1989)
a. Be careful not to damage the oil seal.
B. After installation is finished, pull the front hub slowly outward to check that the driveshaft is held securely by the clip.
11. Install the lower arm ball-joint to the knuckle, and tighten the clinch bolt.
Tightening torque: 43-54 N.m (4.4-5.5 m-kg, 32-40 ft-lb)
12. Install the tie-rod end and new cotter pin.
Tightening torque: 29-44 N.m (3.0-4.5 m-kg, 22-33 ft-lb)
13. Adjust and tighten the stabilizer.
Tightening torque: 16-23 N.m (1.6-2.3 m-kg, 12-17 ft-lb)
Dimension: 20.1 ± 2 mm (0.79 ± 0.079 in)
14. Install the drain plug.
Tightening torque: 39-59 N.m (4.0-6.0 m-kg, 29-43 ft-lb)
15. Install the wheel.
Tightening torque: 88-118 N.m (9.0-12.0 m-kg, 65-87 ft-lb)
16. Add the correct quantity of the specified oil.
Type: All season
ATF: DEXRON II
