MX-6 V6-2496cc 2.5L DOHC (1996)

Page 1
background image

Idle Air Control Valve: Electrical Specifications
BAC Valve Specifications

BAC Valve Specifications

Idle Air Control Valve Solenoid

Resistance

Mounting Bolt Torque









10.7-12.3 ohms at 20 deg C

2.9-4.0 Nm
