MX-6 V6-2496cc 2.5L DOHC (1996)
Throttle Body: Customer Interest
Throttle Body - Stalling/Rough or Rolling Idle
Bulletin No.: 022/96
Issued: 09/09/96
Revised:
Category
F
Applicable Model/s
1993 - 96 626/MX-6
Subject:
THROTTLE BODY SERVICE PROCEDURE FOR CARBON REMOVAL
APPLICABLE MODELS
1993 - 96 626/MX-6
DESCRIPTION
Carbon deposits on the throttle body bore / throttle valve may cause one or more of the symptoms shown.
Customers complaining of these symptoms should have the vehicle inspected and carbon removed according to the instructions in this bulletin. DO NOT
REPLACE THE THROTTLE BODY TO CORRECT THIS CONCERN.
MATERIALS REQUIRED
REPAIR PROCEDURE
1.
Verify the concern.
2.
Remove the throttle body. Refer to section F of the workshop manual.
NOTE:
DO NOT remove the IAC Valve (V6), ISC Valve (4cyl) or the TPS.
3.
Thoroughly clean around the IAC Valve (V6), ISC Valve (4cyl) and the Air Adjust Screw ports in the bore of the throttle body. Use a clean shop
towel for cleaning.
