MX-6 LS V6-2.5L DOHC (1997)

Page 1
background image

Trunk / Liftgate Relay: Service and Repair

Removal / Installation

1. Disconnect the negative battery cable.
2. Remove the trunk side trim.
3. Remove as shown in the figure.
4. Install in the reverse order of removal.
