MX-6 LS V6-2.5L DOHC (1997)
Installation
Installation
^
Tighten the bolts in the order.
Tightening torque:
7.9-11.7 N.m {80-120 kgf.cm, 70-104 in.lbf}
Passenger-Side Air Bag Module
WARNING:
^
Handling the air bag module improperly can accidently deploy the air bag, which may seriously injure you. Read SERVICE
WARNINGS, before handling the air bag module.
^
Installing the passenger-side air bag module when a diagnostic trouble code 7 is not indicated can accidently deploy the air bag, which
can cause serious injury. Carry out the proper troubleshooting procedures and verify that diagnostic trouble code 7 is indicated before
installing the passenger-side air bag module.
1. Carry out the "Before Servicing" procedure.
2. Remove in the order shown.
3. Install in the reverse order of removal.
4. Follow the troubleshooting flowchart to verify that the air bag system is operating normally.
