Protege L4-2.0L DOHC (2003)
4. Disconnect the tensioner spring from the hook pin.
Caution:
^
Forcefully twisting the timing belt turning it inside out, or allowing oil or grease an it will damage the belt and shorten its life.
Note:
^
Mark the timing belt rotation on the belt for proper reinstallation.
Tensioner, Tensioner Spring Installation Note
1. Measure the tensioner spring free length.
^
If not within the specification, replace the tensioner spring.
Free length 36.6 mm (1.44 inch)
2. Install the tensioner.
3. Rotate the tensioner.
^
If tensioner rotates with no resistance or does not rotate, replace the tensioner
Timing Belt Installation Note
