CLS 550 (219.372) V8-5.5L (273.960) (2007)
/v8-5.5l_(273.960)/Page-2848001.png)
Control Assembly: Description and Operation
GF83.40-P-3000TM Automatic Air Conditioning Control and Operating Unit, Component
Description
GF83.40-P-3000TM Automatic Air Conditioning Control And Operating Unit, Component Description
- 219.3 as of 1.6.06
- with CODE (581) Comfort automatic air conditioning
Component Identification
Location
The AAC control and operating unit is located on the instrument panel.
Design
The AAC control and operating unit contains the following controls and displays:
^
Left temperature selector wheel (1)
^
Increase air volume button (2)
^
Display (3)
^
Air distribution button scroll up (4)
^
Right temperature selector wheel (5)
^
Residual heat button (6)
^
AC button (7)
^
Air distribution button scroll down (8)
^
On/off button (9)
^
Reduce air volume button (10)
^
Automatic button (11)
^
Heated rear window switch (N22s1)
^
Air recirculation switch (N22s2)
^
Window defrost switch (N22s3)
The AAC control and operating unit allows the following control actuations:
^
Switch automatic air conditioning (AAC [KLA]) on and off
^
Interior temperature selection separated for the left and right side
^
Manual blower control
^
Manual air distribution
^
Automatic blower control and air distribution
^
Air recirculation mode
^
Defrost function
^
Heated rear window (R1) actuation
