Mass Air Flow Sensor <--> [Air Flow Meter/Sensor] > < Intake Air Cowl|Page 4186

E 320 Coupe (124.052) L6-3.2L (104.992) (1994)

Page 1
background image

Air Filter Element: Locations

Air Cleaner Removal

The air filter is located in the air cleaner housing on passenger side of engine compartment.
