E 320 Coupe (124.052) L6-3.2L (104.992) (1994)
Wiper Motor: Service and Repair
Remove/Install Rubber Seal Below Wiper Gear
Removal:
-
Remove wiper system. See: Remove/Install Wiper Motor
-
Detach wiper linkage from wiper gear. See: Wiper Motor Linkage/Service and Repair
1. Press off locking ring (arrow).
NOTE: Gear head can only be removed in center position. Do not knock out with hammer. When installing, the push rod must be fully inserted;
correct, if neressary, by turning cog wheel (5).
2. Turn gear head into center position (at right angles to notched bar) and withdraw the bearing.
