S 65 AMG (220.179) V12-6.0L Turbo (275.981) (2006)
/v12-6.0l_turbo_(275.981)/Page-1781001.png)
Antenna - Keyless Entry: Service and Repair
AR82.62-P-8000MD Remove/Install Keyless Go Antenna In Trunk
AR82.62-P-8000MD Remove/Install Keyless Go Antenna In Trunk
- with CODE (889) Keyless Go
Illustrated On Model 220 - Left Side
Illustrated On Model 220 - Right Side
1
Remove paneling in trunk
NOTE: Right side, remove right side paneling only
2
Release and remove electrical connector (1) from Keyless Go control module (N69/5)
3
Press locks on left and right antenna elements (A2/35a1, A2/35a2) in trunk in direction of arrow and remove left/right antenna elements (A2/35a1,
A2/35a2)
